This book will describe the computer in great detail. For now, it contains the most recent versions of circuits and ideas.

The Conditional Status describes the result of a data operation. This can be (not exclusive):

Zero     (Z): if the result is zero
Negative (N): if the result is negative
Carry    (C): Arithmetic carry
Overflow (V): if the result does not fit into the destination

Since the Conditional Status refers to a result and this is always kept in some register, detecting status is a job for the register's circuitry. Therefore, each register offers its own means for detecting its own Conditional Status.

The way for registers to deliver their individual status to the Flags register, is by the mean of a 4-bits bus (wired in the Data Slots) called S-BUS.

All registers are constantly generating status signals internally but, at a given time, only one is open to the S-BUS. This is because Flags should only be set according to the register being accessed by the current instruction and only if that instruction is meant to affect flags.

An exception to this rule are those instructions that increment or decrement two registers at the same time (INCM, DECM and INDEC). In this case both registers open to the S-BUS and flags are set as an "OR" of the individual conditions.

There are none dedicated control signals for opening registers to the S-BUS. The selection is made automatically when the register in question is Loaded, Incremented or Decremented.

Registers that are not meant to hold results, won't report conditional status (they are not wired to do so). Those are the following:

-- Program Counter (PC)
-- Stack Pointer (SP)
-- Operand Register (OR)
-- Instruction Register (IR)

The Flags register (F) resides in the Master Controller card (MC) which plugs to both Data and Control slots. The register is 8-bits but only 4 are used to remember the Conditional Status; a 5th. bit is used to remember the Interrupt Enabled condition as we shall see; the remaining 3 bits are implemented but not used (reserved for future use). The whole register F is saved to the Stack during CALL or Interrupt and restored back upon Return.

The register is actually made out of D-type flip-flops (74ACT74) fed from the S-BUS. The outputs go to another bus (called CS-BUS) wired in the Control Slots; this bus is always open so the current status is always available to Controller cards. Flags are latched selectively using signals LD_FZ, LD_FN, LD_FC and/or LD_FV produced by IDS cards during the last cycle of those instructions that affect flags.

Although further analysis on this topic is still pending , I can anticipate the following:

-- ALU instructions affect all flags (Z,N,C,V).
-- Data transfer instructions (MOV, LD, STO, PUSH, POP) affect flags Z, N.
-- Increment/Decrement instructions affect flags Z, N, V.
-- Branch instructions affect none flag.

By not affecting flags, I mean that the previous status remains. The programmer needs to take this into account when placing conditional branch instructions within the code.

The necessity of recording the Interrupt Enabled condition as a flag has to do with nested interrupts. When an interrupt service routine (lets call it: ISR1) gets interrupted by a highest priority interrupt (ISR2), the Interrupt Controller disables interrupts before passing control to ISR2. If this routine failed to enable interrupts back, then interrupts would remain disabled when control returns to ISR1, which is not the intended behavior. But, by remembering the Interrupt Enable condition in the Flags register, interrupts will be automatically restored upon return since F had been saved to the Stack.

Thus there is a flip-flop in F for the Interrupt Enable condition, only that its input (SI) and output (CSI) are not wired with the S-BUS and CS-BUS respectively but treated as point-to-point connections. This is because only a few circuits will make use of them; those circuits are: the Interrupt Controller, the IDS card responsible for the DI and EI instructions and the Control Panel.

The CPU backplane is constructed on a prototyping board holding six 96-pins DIN41612 female connectors and other six 120-pins DIN41612 female connectors. This divides the backplane into two sections: Data Slots and Control Slots respectively. The former is used for "data oriented cards" (such as registers) and the latest is used for "controller cards".

Each of the two Slot types are wired separate. Most of the wires conforms different buses whereas others serve for point-to-point inter-card connections.

A special card named "Master Controller" features two connectors (one 96-pins and the other 120-pis) and plugs to both Slot types. This card contains those circuits that need access to the two worlds such as the Instruction Register (IR), the "Arbitrer" and others. It also provides the interface (buffering) with the external bus (U-BUS).

Following is the pinout for both Slot types:

- - - - - - - - - - - - - -
     A        B       C
- - - - - - - - - - - - - -
1    GND      GND     GND
2    D0       PP      D8
3    D1       PP      D9
4    D2       PP      D10
5    D3       PP      D11
6    D4       PP      D12
7    D5       PP      D13
8    D6       PP      D14
9    D7       PP      D15
10   L0       PP      L8
11   L1       PP      L9
12   L2       PP      L10
13   L3       PP      L11
14   L4       PP      L12
15   L5       PP      L13
16   L6       PP      L14
17   L7       PP      L15
18   RST      PP      L16
19   FLT      PP      L17
20   SZ       PP      L18
21   SN       PP      L19
22   SC       PP      L20
23   SV       PP      CLK
24   A7       PP      A15
25   A6       PP      A14
26   A5       PP      A13
27   A4       PP      A12
28   A3       PP      A11
29   A2       PP      A10
30   A1       PP      A9
31   A0       PP      A8
32   +5V      +5V     +5V
- - - - - - - - - - - - - -

Signals Descriptions:

DO-15       Internal Data Bus
A0-15       Internal Address Bus
L0-20       Internal Lamps Bus
SZ          Set Conditional Status Zero
SN          Set Conditional Status Negative
SC          Set Conditional Status Carry
SV          Set Conditional Status Overflow
RST         System Reset
CLK         System Clock
FLT         Fault Condition
PP          Point-to-Point Control Signals

Except those marked as "PP" (Point to Poin), all signals in Control Slots are wired together in a Bus.
Signals marked as CTL (Control) are not designated yet but they will as the design progresses.

- - - - - - - - - - - - - -
     A        B       C
- - - - - - - - - - - - - -
1    GND      GND     GND
2    IR0      PP      IR8
3    IR1      PP      IR9
4    IR2      PP      IR10
5    IR3      PP      IR11
6    IR4      PP      IR12
7    IR5      PP      IR13
8    IR6      PP      IR14
9    IR7      PP      IR15
10   CTL      CTL     CTL
11   CTL      CTL     CTL
12   CTL      CTL     CTL
13   CTL      CTL     CTL
14   CTL      CTL     CTL
15   CTL      CTL     CTL
16   CTL      CTL     CTL
17   CTL      CTL     CTL
18   RST      CTL     CTL
19   FLT      CTL     CTL
20   CSZ      LD_FZ   CTL
21   CSN      LD_FN   CTL
22   CSC      LD_FC   CTL
23   CSV      LD_FV   CLK
24   CTL      CTL     CTL
25   CTL      CTL     CTL
26   CTL      CTL     CTL
27   CTL      CTL     CTL
28   CTL      CTL     CTL
29   CTL      CTL     CTL
30   CTL      CTL     CTL
31   CTL      CTL     CTL
32   CTL      CTL     CTL
33   CTL      CTL     CTL
34   CTL      CTL     CTL
35   CTL      CTL     S1
36   CTL      CTL     S0
37   CTL      CTL     EOE
38   CTL      CTL     ET1
39   CTL      CTL     ET0
40   +5V      +5V     +5V
- - - - - - - - - - - - - -

Signals Descriptions:

IR0-15      Instruction Register Output
CSZ         Conditional Status Zero
CSN         Conditional Status Negative
CSC         Conditional Status Carry
CSV         Conditional Status Overflow
LD_FZ       Load Flag Zero
LD_FN       Load Flag Negative
LD_FC       Load Flag Carry
LD_FV       Load Flag Overflow
S0, S1      Operational Status
ET0, ET1    Enconded Time (T1, T2, T3, T4)
RST         System Reset
CLK         System Clock
FLT         Fault Condition
CTL         Control Signals (Bus)
PP          Control signals (Point-to-Point)


Encoded Time:

- - - - - - - - -
ET1   ET0   Time
- - - - - - - - -
0    0     T1
0    1     T2
1    0     T3
1    1     T4
- - - - - - - - -

Operational Status:

- - - - - - - - - - - - - - - - - - - -
S1   S0   Operational Status
- - - - - - - - - - - - - - - - - - - -
0    0    Halt
0    1    Fetch
1    0    Execute
1    1    Interrupt being negotiated
- - - - - - - - - - - - - - - - - - - -
